CABLE

ED.Methodes

For the intelligent design of wiring documentation
Using standard E3series datas (views, attributes)

The graphics and connector outputs are fully configurable and compatible with the standard functions of E3series

Full Windows module available in 32/64 bits version (7, 8, 10, WindowsServer 2008 >)

Compatible E3.cable 2011 and higher
Language available:
English / French / Other languages possible

Software with licenses.

Lire la vidéo

CABLE | SCHEMATIC

ED.Wirecolor

EDWirecolor changes the connection color according to the wire or cable core.
This program also allows the filling of masters pines.
It controls the type of line and its associated color as defined in the configuration database.
The « Auto » mode is included, ie as soon as a thread is placed or removed, the color and the type of line change. Placed masters are automatically updated

Settings allow to choose specific colors for white wires

Full Windows module available in 32/64 bit version (7, 8, 10, WindowsServer 2008 >)
Compatible E3.Schematic /E3.cable 2011 and higher
Language available:
English / French / Other languages possible

PANEL

ED.PanelPlacement

Allows automatic placement of free E3 models on the mounting rails.
On each rail is indicated the alphabetic code of the device which one wishes to pose.
If the rail is not suitable, the program will not place it.

Full Windows module available in 32/64 bit version (7, 8, 10, WindowsServer 2008 >)
Compatible E3.Panel 2011 and higher
Language available:
English / French / Other languages possible

Lire la vidéo
Lire la vidéo

CABLE | SCHEMATIC

ED.SwapCore

This tool reverses the direction of the cable core or wires for better
list output logic

Full Windows module available in 32/64 bit version (7, 8, 10, WindowsServer 2008 >)
Compatible E3.Schematic /E3.cable 2011 and higher
Language available:
English / French / Other languages possible

CABLE | SCHEMATIC| FLUID

ED.Preview

Plug-in for placement in the drawing of predefined symbols.
Adding or removing a symbol is simple.

Full Windows module available in 32/64 bit version (7, 8, 10, WindowsServer 2008 >)
Compatible E3.Schematic /E3.cable 2011 and higher
Language available:
English / French / Other languages possible

Lire la vidéo
